Protable Fiber Laser Marker Machine for Eyeglasses Case Eyeglasses Accessories
(Model:Man-50)
(Model:Man-50)
1.laser source from Germany, and master the core technology same as Germany
2.Imported high-speed scanning galvanometer from Singapore with photoelectric conversion efficiency,
3.fiber laser, long life, high marking speed, high quality output beam, high reliablity.
4.Can be integrated in the industrial mass production process.
5.Air cooling, except electricity, no other consuption
Fiber Laser Marker Engraver Machine Characters Features
1. Best Marking Effect: the laser beam of color laser printer fiber laser mark machine is fine and thin. It can provide the best marking effect among all the laser machine machines. Especially good in smallest character marking, such as mark on IC chip.
2. Deep Marking: Perfect Laser's color laser printer fiber laser mark machine can make deep marking up to 1.0mm on stainless steel and aluminum. While YAG and Diode marking only could mark 0.2mm-0.3mm.
3. Higher Accuracy:color laser printer fiber laser mark machine can reach unto 0.001mm precision, while diode only 0.01mm.
4. 10 Years Long lifetime: We used the fiber laser module made by Germany IPG technology, the lifetime of the fiber laser device is 100,000 hours, so the machine can be used for 8-10 years.
5. No consumables: color laser printer fiber laser mark machine can be used for 8-10 years without any consumables.
6. No need to adjust the laser path.
7. Free of Maintenance.
8. Use Integrated Air Cooling.
9. Low Power Consumption: low cost, only 0.5kw/hour.
| Output power | 50w |
| Central wavelength | 1064±4nm |
| Polarization | Random |
| Single pulse power | 0.8~1.0mJ |
| Beam quality | <1.7m2 |
| Facular diameter | 7~9mm |
| Power stability | <5% |
| Frequency adjusting range adjustable range | 20~80kHz |
| Pulse breadth | 80~140ns |
| Pulse adjusting range | 5~100% |
| operating voltage | 100~240VAC |
| Fiber Length | 1.5m |
| Cooling mode | forced air |
| Operation temperature | 0~35ºC |
| Operation humidity | 10~95 |
| Storage temperature | -10~60ºC |
| Marking Format | Graphics, Text, Bar Codes, QR Code, Serial Number,Serial number,etc. |
Fiber Laser Marker Engraver Machine Characters
1. Used to mark on various metals.
2. Used to mark on flat or rotary surface
3. Adequate for marking characters, letters, serials numbers and VIN codes, etc.
4. XP/ windows operation system with marking software installed.
1) Free Training by VCD:We will supply the machine with <Training VCD> , <User's Manual> and <Instruction Book> in English for installing, operation, maintenance and trouble-shooting, and shall give technical guide by E-mail, fax, telephone, MSN, ICQ and so on, when you meet some problems of installation, using or adjusting.(Recommend)
2) Free Training Factory:You can send operator to laser marker factory for free training. Laser marker will offer professional guide for free.It is direct and effective face-to-face training.Here we have well-assembled equipments, all sorts of tools and testing facility.
Training Time:2-3 days (Recommend)
3) Our engineer can do a door-to-door instruction training service at your local site.We need your help to deal with the visa formality, prepaid traveling expenses and accommodation to us during the business trip and service period before their dispatch.It's better to arrange a translator for both of our engineers during the training period.
Quality Guarantee and After-sales Services:
1)The guarantee period of quality shall be 12 months counting from the date on which the commodity arrives at the port of destination.Except the damage artificially and laser krypton lamp, we are responsible for offering the fittings free of charge during the guarantee period.While user is kindly requested to send the damaged fittings to us by courier with your charge before we send back the alternative fitting parts.After the guarantee of quality period, the parts required repairing or change, if any, shall be reasonable charged.
2)We will give technical guide by email, fax and telephone when user meets some problems on installation, operation, adjusting, maintaining.
3)We offer technical supporting to ensure safety using & maintenance for user:
Operation manual for installation, adjusting, operation, maintaining;
Professional marking software;
Opeatrional marking software backup;
Quick supplement of key componentsUU with reasonable price.
Life-long after-sales service & consulting service to user.
Packing&Shipping:
2) Free Training Factory:You can send operator to laser marker factory for free training. Laser marker will offer professional guide for free.It is direct and effective face-to-face training.Here we have well-assembled equipments, all sorts of tools and testing facility.
Training Time:2-3 days (Recommend)
3) Our engineer can do a door-to-door instruction training service at your local site.We need your help to deal with the visa formality, prepaid traveling expenses and accommodation to us during the business trip and service period before their dispatch.It's better to arrange a translator for both of our engineers during the training period.
Quality Guarantee and After-sales Services:
1)The guarantee period of quality shall be 12 months counting from the date on which the commodity arrives at the port of destination.Except the damage artificially and laser krypton lamp, we are responsible for offering the fittings free of charge during the guarantee period.While user is kindly requested to send the damaged fittings to us by courier with your charge before we send back the alternative fitting parts.After the guarantee of quality period, the parts required repairing or change, if any, shall be reasonable charged.
2)We will give technical guide by email, fax and telephone when user meets some problems on installation, operation, adjusting, maintaining.
3)We offer technical supporting to ensure safety using & maintenance for user:
Operation manual for installation, adjusting, operation, maintaining;
Professional marking software;
Opeatrional marking software backup;
Quick supplement of key componentsUU with reasonable price.
Life-long after-sales service & consulting service to user.
Packing&Shipping:
